Tantalum Titanium Alloy Powder

tantalum titanium alloy powder

Tantalum Titanium Alloy Powder

  • Custom sizes and standard sizes in stock
  • Quick Lead Time
  • Competitive Price

Tantalum Titanium Alloy Powder is a high-performance alloy powder offering excellent high-temperature and corrosion resistance and good mechanical properties. As a leading supplier and manufacturer of premium tantalum products, Shanghai Yuepeng utilizes advanced machining centers to produce high-quality tantalum titanium alloy powder for a wide range of applications.

Get a Quote

Tantalum Titanium Alloy Powder Data Sheet

Purity:>99.9%
Material:TaTi Alloy (the composition ratio can be customized according to specific requirements)
Particle Size:-500 mesh, -300 mesh, -200 mesh, -100 mesh, or customized
Morphology:Irregular or Spherical

Tantalum Titanium Alloy Powder

Tantalum Titanium Alloy Powder is primarily composed of tantalum and titanium elements, offering exceptional high-temperature and corrosion resistance. The composition ratio and particle sizes can be customized according to specific requirements. To meet diverse application requirements, we have also developed a comprehensive range of high-performance powder products, including high-purity tantalum powder, low-oxygen tantalum powder (oxygen content as low as 200ppm), low-oxygen niobium powder (oxygen content as low as 400ppm), C103 niobium alloy powder, Tantalum Tungsten Alloy Powder, etc.

  • tantalum titanium alloy powder

Tantalum Titanium Alloy Powder Applicable Process

  • Metal Injection Molding (MIM)
  • Additive Manufacturing (AM)
  • Hot Isostatic Pressing (HIP)
  • Thermal Spray Coating

Tantalum and Tantalum Alloy Grades

  • R05200, unalloyed tantalum, electron-beam furnace vacuum-arc melt, or both
  • R05400, unalloyed tantalum, powder-metallurgy consolidation.
  • R05255, tantalum alloy, 90 % tantalum, 10 % tungsten, electron-beam furnace of vacuum-arc melt, or both.
  • R05252, tantalum alloy, 97.5 % tantalum, 2.5 % tungsten, electron-beam furnace or vacuum-arc melt, or both.
  • R05240, tantalum alloy, 60 % tantalum, 40 % niobium, electron-beam furnace or vacuum-arc melt.

Tantalum Titanium Alloy Powder Applications

  • Aerospace: Due to its excellent high-temperature resistance and corrosion resistance, tantalum-titanium alloy powder is used in manufacturing components for aerospace vehicles, such as engine parts and fuel systems.
  • Electronics: In the electronics industry, tantalum-titanium alloy powder is used to produce high-performance electronic components, such as capacitors and resistors.
  • Medical Devices: Tantalum-titanium alloy, with its excellent biocompatibility, is widely used in manufacturing artificial joints, bone implants, and other medical devices.
  • Chemical Industry: Tantalum-titanium alloy powder is used to produce corrosion-resistant equipment and components, which are widely applied in chemical reactors, heat exchangers, and other devices.
  • 3D Printing: Tantalum-titanium alloy powder is also used in 3D printing technologies, especially for manufacturing complex shapes and high-performance components, offering a wide range of application prospects.
  • Defense and Aerospace

    • Tantalum Titanium Alloy Powder Packaging

    The high-quality tantalum titanium alloy powder will be carefully handled to prevent damage during storage and transportation. Shanghai Yuepeng offers vacuum-sealed packaging, including 100g/bag, 500g/bag, 1kg/bag, and 25kg/drum, or can offer customized packaging as per specific requirements.

    Tantalum Properties

    ItemValue
    Atomic number73
    Crystal structureBody centred cubic
    Electronic structureXe 4f¹⁴ 5d³ 6s²
    Valences shown2,3,4,5
    Atomic weight( amu )180.9479
    Thermal neutron absorption cross-section( Barns )22
    Photo-electric work function( eV )4.1
    Natural isotope distribution( Mass No./% )180/ 0.012
    Natural isotope distribution( Mass No./% )181/ 99.988
    Atomic radius – Goldschmidt( nm )0.147
    Ionisation potential( No./eV )1/ 7.88
    Ionisation potential( No./eV )2/ 16.2
    ItemValue
    Material conditionUnannealed (Hard)
    Material conditionAnnealed (Soft)
    Poisson’s ratio0.342
    Poisson’s ratio0.342
    Bulk modulus( GPa )196.3
    Bulk modulus( GPa )196.3
    Tensile modulus( GPa )185.7
    Tensile modulus( GPa )185.7
    Hardness – Vickers( kgf mm⁻² )200
    Hardness – Vickers( kgf mm⁻² )90
    Tensile strength( MPa )760
    Tensile strength( MPa )172-207
    Yield strength( MPa )705
    Yield strength( MPa )310-380
    ItemValue
    Electrical resistivity( µOhmcm )13.5@20@20°C
    Superconductivity critical temperature( K )4.47
    Temperature coefficient( K⁻¹ )0.0035@0-100°C
    Thermal emf against Pt (cold 0C – hot 100C)( mV )0.33
    ItemValue
    Boiling point( °C )5425
    Density( gcm⁻³ )16.6@20°C
    ElementValue
    Melting point( °C )2996
    Latent heat of evaporation( J g⁻¹ )4165
    Latent heat of fusion( J g⁻¹ )174
    Specific heat( J K⁻¹ kg⁻¹ )140@25°C
    Thermal conductivity( W m⁻¹ K⁻¹ )57.5@0-100
    Coefficient of thermal expansion( x10⁻⁶ K⁻¹ )6.5@0-100°C

    Download

    • Company Profile

    Get A Quote

    We will check and get back to you in 24 hours.

    To customize your tantalum titanium alloy powder, please provide the following details:

    1. Purity (Specify the purity level)
    2. Particle Size (Required size range)
    3. Morphology (Spherical, irregular, etc.)
    4. Quantity of the powder you need

    Once we have these details, we can provide you with a quote within 24 hours.

    We carry a wide variety of tantalum and tantalum alloy products in stock, and for these, there is generally no minimum order requirement. However, for custom orders, we typically set a minimum order value of $200. The lead time for stock items is usually 1-2 weeks, while custom orders usually take 3-4 weeks, depending on the specifics of the order.

    DFARS (Defense Federal Acquisition Regulation Supplement) compliance is primarily concerned with the sourcing of materials for defense-related applications in the United States. According to DFARS, certain materials used in defense must be sourced from the United States or qualifying countries.

    If you have specific tantalum materials that are subject to DFARS, please let us know in advance and we will confirm.

    At Shanghai Yuepeng Tech, we take this responsibility seriously. We adhere to all applicable laws and regulations, including Section 1502 of the Dodd-Frank Act. Our company operates with a strict code of ethics and is committed to only partnering with suppliers who share our dedication to responsible sourcing. We support the initiatives and programs aimed at promoting “conflict-free” supply chains and work diligently to ensure that our products meet these standards.

    Tantalum titanium alloy powder is a metallic powder produced by melting and powder metallurgy techniques, blending Tantalum (Ta) and Titanium (Ti). It combines the ultimate corrosion resistance, high density, and radiopacity of Tantalum with the high strength, low density, and biocompatibility of Titanium, resulting in a high-performance advanced material known for its exceptional overall properties.

    It offers significant advantages:

    • Excellent biocompatibility with minimal tissue reaction.
    • Elastic modulus closer to human bone, reducing “stress shielding” and promoting osseointegration.
    • Extreme resistance to bodily fluid corrosion, ensuring long-term stability and safety.
    • Excellent radiopacity (due to Ta), facilitating post-operative X-ray monitoring.

    The choice depends on the application:

    • For ultimate corrosion resistance and biocompatibility, choose a higher Tantalum content (e.g., Ti-30Ta).
    • For lower density and higher strength, a moderate or lower Tantalum content (e.g., Ti-10Ta) may be suitable. The optimal composition requires performance testing and printing process trials.

    The optimal composition requires performance testing and printing process trials.

    Shanghai Yuepeng Tech, established in 2022 in Shanghai, China, is a specialized supplier and manufacturer of tantalum and tantalum alloys. With extensive expertise in supply and export, we offer competitive pricing and customized solutions tailored to specific requirements, ensuring outstanding quality and customer satisfaction. As a professional provider of refractory metals, specialty alloys, spherical powders, and various advanced materials, we serve the research, development, and large-scale industrial production needs of the scientific and industrial sectors.
